Product Summary

Case: Molded plastic with heatsink integrally mounted in the bridge encapsulation
Terminals: Either plated 0.25" (6.35mm). Faston lugs or plated copper leads 0.040"
(1.02mm) diameter. Suffix letter "W" added to indicate leads (e.g. GBPC12005W).
Mounting Position: See NOTE 3
Polarity: Polarity symbols molded on body
Mounting Torque: 20 in. - lb. max.     Weight: 0.53 ounce, 15 grams

Parametrics

Mobile:86-13728616604
Tel: 86-755-23614041
Yahoo: sunnylu8881@yahoo.com
Skype: sunnylu8881
MSN: sunnylu.sep@hotmail.com



Features

? The plastic package has Underwriters Laboratory Flammability Classification 94V-0
? This series is UL recognized under component index, file number E54214
? Integrally molded heatsink provides very low thermal resistance for maximum heat
dissipation
? Universal 3-way terminals; snap-on, wire wrap-around, or P.C.B. mounting
? High forward surge current capabilities
? Glass passivated chip junctions
? Typical IR less than 0.3μA
? High temperature soldering guaranteed:
260°C/10 seconds at 5lbs. (2.3 kg) tension
